V230-13-B20B

V230-13-B20B

ELDAS®:

Current type DC
Nominal voltage 12 V-24 V

Back-up battery 7 years typical at 25 °C, battery back-up for RTC and system data, including variable data
Ingress Protection IP 65 / NEMA4X (Panel mounted)
Mounting Panel with brackets
Operation temperature 0 … 50 °C / 32 ... 122 °F
Relative huminity, no condensation 5 ... 95 %
Storage temperature (no ice) -20 … 60 °C / -4 ... 140 °F
Weight 429 g

Display 3.2” display, STN, LCD
Number of definable displays 255
Number of keys 24
Resolution 128 x 64 pixels

Execution time 30 µs / Kb
Number of ladder code memory (virtual) 1000
Number of memory bits (coils) 4096
Number of memory integers (registers) 2048
Number of timers 192

Nominal voltage 12 … 24 V DC
Operating voltage range 10.2 … 28.8 V DC
Power consumption AC / DC - / 2.5 W

Approvals UKCA,CE,cULus
