SSU33R/AC400V 50 HZ
- 1 changeover contact
- Contact material AgNi
- Pluggable
- Monitoring: phase sequence, phase failure, undervoltage, overvoltage, frequency
- Contact material AgNi
- Pluggable
- Monitoring: phase sequence, phase failure, undervoltage, overvoltage, frequency
ELDAS®:
7630005161401
| Current type | AC (50 Hz) |
|---|---|
| Nominal voltage | 400 V |
| Housing material | PC |
|---|---|
| Ingress Protection | IP 20 |
| Operation temperature | -25 … 60 °C |
| Storage temperature (no ice) | -40 … 85 °C |
| Weight | 300 g |
| Overvoltage category | III |
|---|---|
| Pollution degree | 2 |
| Rated test voltage measuring / measuring circuit | 2 kV rms / 1 min |
| Rated test voltage measuring circuit / main circuit | 2 kV rms / 1 min |
| Rated test voltage open contact | 1 kV rms / 1 min |
| Contact materials | AgNi |
|---|---|
| Mechanical endurance (cycles) | 30 000 000 |
| Minimum load | 10 mA, 5 V |
| Number of contacts | 1 CO |
| Rated current | 6 A |
| Rated load AC-1 | 1500 VA |
| Rated voltage | 250 V AC |
| AC voltage measurement range L-N / L-L | - / 280 … 480 V |
|---|---|
| Alarm delay | 0.2 … 5 s |
| Frequency difference setting range L-N / L-L | 3 … 15 Hz |
| Measured parameters | U, ΔPhi, Δf |
| Monitoring functions | Under, over, phase failure, phase sequence |
| Number of voltage measurement inputs | 3 (L1 / L2 / L3) |
| Overvoltage setting range | ≥ 480 V |
| Phase angle difference setting range L-N / L-L | 3 … 15° |
| Rated AC voltage L-N / L-L | - / 400 V |
| Rated base frequency | 50 Hz |
| Undervoltage setting range | ≤ 280 V |
| Voltage difference setting range L-N / L-L | - / 35 … 173 V |
| Frequency range | 50 Hz |
|---|---|
| Nominal voltage | 400 V AC |
| Operating voltage range | 280 … 470 V |
| Power consumption AC / DC | 3 VA / - |
| Approvals | UKCA,CE,EAC,Railway |
|---|---|
| Railway | EN 50155,EN 45545-2 |
| Standards | IEC/EN 60947 |
