CT524R/DC24V
- DC voltage monitor 0-30 V
- For plug-in socket S3-M0, S3-M0R, S5-M, S5-MR
- Monitoring: overvoltage and undervoltage
- For plug-in socket S3-M0, S3-M0R, S5-M, S5-MR
- Monitoring: overvoltage and undervoltage
ELDAS®:
7630005158456
| Current type | DC |
|---|---|
| Nominal voltage | 24 V |
| Housing material | PC |
|---|---|
| Ingress Protection | IP 20 |
| Operation temperature | -40 … 70 °C |
| Storage temperature (no ice) | -40 … 85 °C |
| Weight | 25 g |
| Alarm delay | 100 ms / 500 ms / 2 s |
|---|---|
| Alarm reset delay | 100 ms |
| DC voltage measurement range U+ / U- | 0 … 30 V |
| Measured parameters | U |
| Monitoring functions | Under, over, inside, outside |
| Overvoltage setting range | 0 … 30 V |
| Undervoltage setting range | 0 … 30 V |
| Nominal voltage | 24 V DC |
|---|---|
| Operating voltage range | 18 … 30 V |
| Power consumption AC / DC | ≤ 0.5 W |
| Approvals | UKCA,CE,EAC,Railway |
|---|---|
| Railway | EN 50155,EN 45545-2 |
| Standards | EN 60947-1,EN 61000-6-3,EN 61000-6-2 |
