CT33R/UC24-48V

‘- pluggable in base
- Time functions: E, A, N, L, F, K, G, B1, Q, W, H, B
- Time range 30 ms - 60 h

ELDAS®: 528776272

Current type	AC / DC (50 Hz)
Nominal voltage	24 V-48 V

Current consumption on supply A1-A2 AC / DC	11 mA / 11 mA
Frequency range	0; 40 … 60 Hz
Nominal voltage	24 … 48 V AC/DC
Operating voltage range	19 … 60 V AC/DC
Power consumption AC / DC	0.3 VA / 0.3 W
Threshold voltage on input control B1 AC / DC	9 V / 9 V

Timing range	30 ms … 150 ms / 120 ms … 600 ms / 0.3 s … 1.5 s / 1.2 s … 6 s / 3 s … 15 s / 12 s … 60 s / 0.3 min … 1.5 min / 1.2 min … 6 min / 3 min … 15 min / 12 min … 60 min / 0.3 … 1.5 h / 1.2 min … 6 h / 3 h .. 15 h / 12 … 60 h
Timing scale	30 ms … 60 h
