S3-L (SK-3006)
5-pin socket for R10 relay
ELDAS®:
| - Terminal / terminal | 2.0 kVAC |
|---|---|
| Housing material | Stainless steel / ABS |
| Insulation rating between all ports | > 1GΩ |
| Mounting | Back mounting |
| Operation temperature | -40 … 85 °C |
| Rated load | 10 A / 250 V |
| Storage temperature (no ice) | -40 … 85 °C |
| Weight | 15 g |
| Approvals | UKCA,CE |
|---|---|
| Standards | IEC 60664-1 |
Approvals
