CCMB3H425
- 3-pole
- Thyristor
- 25 A @ 400 V
- Thyristor
- 25 A @ 400 V
ELDAS®:
501111215
| Brake current | 0 … 85 % |
|---|---|
| Frequency range | 50 / 60 Hz |
| Operating voltage range | 24 ... 230 V AC/DC |
| Overvoltage category | III |
| Pick-up time | 100 ms |
| Pollution degree | 3 |
| Ramp-up time | 0.5 … 10 s |
| Release time | 100 ms |
| Release voltage | 5 V AC/DC |
| Torque adjustment | 0 … 85 % |
| Ambient temperature operation derated power | -5 ... 60 °C |
|---|---|
| Conductor cross section control / main circuit | 2.5 mm2 / 6 mm2 |
| Housing material | PPE |
| Ingress Protection | IP 20 |
| Mounting | TH35 (EN 60715) or back panel mounting |
| Operation temperature | -5 ... 40 °C |
| Storage temperature (no ice) | -20 ... 80 °C |
| Weight | 1 050 g |
| Bypass | Externally |
|---|---|
| Controlled phases | 2 |
| Inrush current | 200 A |
| Leakage current | 5 mA |
| Minimum load | 1 A |
| Number of outputs | 3 |
| Output type | SCR |
| Output voltage range | 400 … 480 V AC |
| Peak reverse voltage | 1650 Vrrm |
| Rated current AC-53a | 25 A |
| Rated limit load | 6300 Asup2/sups |
| Rated voltage | 400 V |
| Reverse voltage | 1600 Vrrm |
| Approvals | UKCA,CE,cULus |
|---|---|
| Standards | IEC/EN 60947-4-2 |
